Class Reference

Overview

* Classes by Category *

Alphabetical Class Listing

Overview

Class Index (Alphabetical)

1. Alphabet

2. AminoAlphabet

3. BinomialDistribution

4. BoundedSortedArray

5. DnaAlphabet

6. LowercaseDnaAlphabet

7. Environment

8. FSPLIterator

9. FixedSizePriorityList

10. FixedSizePriorityQueue

11. MemoryProfiler

12. Sequence

13. Symbol

14. TigrArray1D

15. TigrArray1DSorter

16. TigrArray2D

18. TigrBinaryTree

19. TigrBinTreeIter

20. TigrBitSet

21. TigrChi2FitTest

22. TigrChi2IndepTest

23. TigrChi2Table

24. TigrCommandLine

25. TigrComparator

26. DirectComparator

27. TigrComplexNum

28. TigrConfigFile

29. TigrContingencyTbl

30. TigrDblMatrix;

31. TigrElasVector

32. TigrElasDblVect

33. TigrElasFloatVect

34. TigrElasIntVect

35. TigrElasCharVect

36. TigrElasLongVect

37. TigrEntropy

38. RootException

39. FileErrorException

40. ArrayIndexException

41. TigrFastaReader

42. TigrFastaWriter

44. TigrFastBinTree

45. TigrFile

46. TigrGaussJordan

48. TigrGffExon

49. TigrGffFeature

50. TranscriptComparator

51. TigrGffReader

52. TigrGffTranscript

53. TigrHugeFastaReader

55. TigrInversionMatrix

56. TigrIterator

57. TigrJointDistr

58. TigrLinearFunc

59. TigrLinRegressor

60. TigrList

61. TigrListQueue

63. TigrMap

64. TigrMemStream

65. TigrMultRegress

66. TigrMutInfo

67. TigrPipe

68. TigrPriorityTree

69. TigrProgress

70. TigrProteinTrans

71. TigrRealVector

72. TigrRegex

73. TigrSet

74. TigrSmartPointer

75. TigrSparseGraph

76. TigrStack

78. TigrStacktrace

79. TigrStandardDev

80. TigrString

81. StringMapIterator

82. TigrStringMap

83. TigrStrTokenizer

84. TigrSummaryStats

85. TigrTime

86. TigrTriangMatrix

87. TigrVector

88. TigrVectorSorter

89. TigrWindowedQueue

class Alphabet
Represents an arbitrary alphabet of discrete symbols, whether DNA, amino acids, or other.  Consists of Symbol objects (which are interchangeable with native ints).
Alphabet(const char * = NULL);	constructor
int add(char);	Add a character to the alphabet.
bool load(istream &);	Load alphabet from file.
int getNumElements() const;	Size of alphabet.
inline char lookup(int) const;	Get the ith symbol in the alphabet.
inline int lookup(char) const;	Get the index of a given symbol.
void printOn(ostream &);	Display alphabet on stream.
char complement(char);	Crick-Watson DNA complement of symbol
Symbol complement(Symbol);	Crick-Watson DNA complement of symbol
bool save(ostream &);	Write alphabet into file.
bool isDefined(char) const;	Check whether symbol is present in alphabet.

class AminoAlphabet : public Alphabet
An alphabet of amino acid symbols.
AminoAlphabet();	constructor
static AminoAlphabet global;	Global instance of this class.

class BinomialDistribution
Represents a binomial distribution.
static inline double density(int exactNumSuccesses, int numTrials, double probSuccess);	Returns P(s|n,p)=probability of observing exactly s successes in n bernoulli trials, given probability of sucess p.
static double rightTailedPValue(int thisManyOrMoreSuccesses,int numTrials, double probabilityOfSuccess);	Returns P(s|n,p)=probability of observing s or more successes in n bernoulli trials, given probability of sucess p.

template<class ObjectType,class ScalarType>
class BoundedSortedArray
An array that has a fixed size.  Elements are kept sorted.  If you add too many things to the array, elements are lost out the left or right side.
BoundedSortedArray(int size,KeepType);	constructor.  KeepType= {KEEP_LOW_VALUES, KEEP_HIGH_VALUES}.  ScalarType should be int,float,double, etc. for maintaining the ordering of the array.
bool add(const ObjectType &,ScalarType);	Insert an element into the array, with a value for maintaining sorted order.
ObjectType &operator[](int);	Access element of array.
const ObjectType &operator[](int) const;	Access element of const array.
ScalarType getValue(int i) const;	Access the scalar value of array element.

class DnaAlphabet : public Alphabet
Alphabet containing symbols {A,T,C,G,N}.
DnaAlphabet();	constructor
static DnaAlphabet global;	Global instance of this object.

class LowercaseDnaAlphabet : public Alphabet
Alphabet containing symbols {a,t,c,g,n}
LowercaseDnaAlphabet();	constructor
static LowercaseDnaAlphabet global;	Global instance of this object.

class Environment
Allows access to UNIX environment variables.
static TigrString lookup(const TigrString &);	Look up given environment variable.

template <class T>
class FSPLIterator : public TigrIterator<T>
Iterator for FixedSizePriorityList.  Defined in FixedSizePriorityList.H.
FSPLIterator(typename TigrList<T>::iterator);	constructor
FSPLIterator();	constructor
virtual void operator++();	Advance to next element
virtual void operator++(int);	Advance to next element
virtual T &operator*();	Access this element
virtual bool operator==(const TigrIterator<T> &) const;	Compare iterators
virtual bool operator!=(const TigrIterator<T> &i) const	Compare iterators
virtual TigrIterator<T> &clone();	Clone iterator
operator typename TigrList<T>::iterator();	Cast this iterator to a TigrList::iterator

template <class T>
class FixedSizePriorityList
A linked list having a maximum size.  If you insert too many elements, the smallest elements are deleted to maintain the size restriction.
FixedSizePriorityList(int capacity, TigrComparator<T>& = *new DirectComparator<T>());	constructor
int getCapacity() const;	Returns maximum size of list
int size() const;	Returns current size of list
bool empty() const;	Returns true if list is empty
bool insert(T);	Adds element to list
bool push_back(T t);	Adds element to list (same as insert)
T &getMin();	Returns smallest element
T &getMax();	Returns largest element
FSPLIterator<T> begin();	Starting iterator
FSPLIterator<T> end();	Ending iterator
void erase(FSPLIterator<T>);	Remove an element from the list
void clear();	Remove all elements ffrom the list

template <class T>
class FixedSizePriorityQueue
A priority queue implemented as a fast binary tree (i.e., nodes have pointers to children and parent) and with a fixed capacity, so that when the queue is full, each insertion causes the smallest element to fall out of the queue.
FixedSizePriorityQueue(int capacity, TigrComparator<T>& = *new DirectComparator<T>());	constructor
int getCapacity() const;	Returns maximum# elements that will fit
int getNumElements() const;	Returns number of elements in the queue
bool isEmpty() const;	True iff queue is empty
bool insert(T);	Add element to queue
T &peekMin() const;	Returns minimum element, no removal
T &peekMax() const;	Returns max element; no removal
TigrFastBinTree<T>:: iterator begin();	Starting iterator
TigrFastBinTree<T>:: iterator end();	Ending iterator

class MemoryProfiler
LINUX-specific class for monitoring memory usage of the current program during execution.
static void report(const TigrString &label,ostream & =cout);	Prints a message to the ostream reporting current memory usage

class Sequence
A sequence of discrete Symbols.
static Sequence *load(const TigrString &filename,Alphabet &, TigrString &substrateId);	Loads the sequence with the given substrateId (after the '>' on the defline) from the given file
static Sequence *load(const TigrString &filename,Alphabet &);	Loads the first sequence from the given file
Sequence(const TigrString &,Alphabet &);	constructor - builds a Sequence from the given string under the given alphabet
Sequence();	constructor - builds an empty Sequence
Sequence(const char *,Alphabet &);	constructor - builds a Sequence from the given string under the given alphabet
virtual ~Sequence();	destructor
void copyFrom(const TigrString &,Alphabet &);	Make this sequence identical to that sequence
void setPhase(int);	Associate a phase value with this sequence
int getPhase() const;	Get the phase value that was previous set via setPhase()
void append(Symbol);	Append a single symbol to the sequence
void append(const Sequence &);	Append another sequence to the end of this sequence
void prepend(Symbol);	Prepend a single symbol to the beginning of this sequence
Symbol operator [](int) const;	Access the const symbol at the given index
Symbol &operator [](int);	Access the symbol at the given index
const Sequence &operator=(const Sequence &);	copy assignment operator
int getLength() const;	Returns length of sequence
void printOn(ostream &) const;	Prints sequence on an ostream as a sequence of integers (using the int encoding internal to the alphabet)
void printOn(ostream &,Alphabet &) const;	Prints sequence on ostream as sequence of characters, as defined by alphabet
TigrString *toString(Alphabet &,int startingAt=0) const;	Convert sequence object to string, with optional offset index
void clear();	Become the empty sequence
virtual void getSubsequence(int begin,int len,Sequence &s) const;	Copies subsequence of this sequence into s
bool subsequenceOccursAt(const Sequence &s,int pos) const;	True iff s occurs as a substring of this sequence at position pos
Sequence *reverseComplement(Alphabet &) const;	Returns the Watson-Crick reverse complementary sequence of this one
void reverseComplement(Alphabet &,Sequence &) const;	Computes reverse complement into the provided sequence
bool isEmpty() const;	True iff this sequence is empty

class Symbol
A single symbol in an Alphabet.  Represented as an int value.  Requires use of Alphabet to translate into char lexeme.  Can be stored in Sequences.
Symbol(int =0);	constructor
bool operator==(const Symbol &);	Same as that symbol?
operator int() const;	Get underlying int representation.
int getIndex() const;	Get underlying int representation.
Symbol &operator++();	Get symbol with next higher in value

template<class T>
class TigrArray1D
Single-dimensional fixed-size array of objects of type T.  Define DEBUG to turn on bounds-checking.
TigrArray1D(int size);	constructor - build array of given size
TigrArray1D(const TigrArray1D &);	copy constructor
virtual ~TigrArray1D();	destructor - deallocates array (but not objects pointed to if T is a pointer!)
T &operator[](int);	Access element at given index.
const T &operator[](int) const;	Access element at given index.
int size() const;	Returns capacity of array (# elements)
void printOn(ostream &os);	Print on ostream (used by operator <<)
void resize(int newSize);	Delete array and reallocate to given size
void setAllTo(T);	Store given value at all locations
void saveBytes(TigrFile &);	Write raw byte representation into file
void loadBytes(TigrFile &);	Read raw byte representation from file
TigrArray1D<T> &operator=(const TigrArray1D<T> &);	Copy assignment operator

template <class T>
class TigrArray1DSorter
A class that can sort the elements of a TigrArray1D<T>, given a TigrComparator for T.
TigrArray1DSorter(TigrArray1D<T> &,TigrComparator<T> &);	constructor - the comparator must define the desired ordering
TigrArray1D<T> *sortAscending();	Sort the elements in ascending order and return the resulting array (original array unmodifed)
TigrArray1D<T> *sortDescending();	Sort the elements in descending order and return the resulting array (original array unmodified)
TigrArray1D<int> *sortAscendByIndex();	Returns array of indices of progressive elements in sorted order (ascending), without modifying the original array
TigrArray1D<int> *sortDescendByIndex();	Returns array of indices of progressive elements in sorted order (descending), without modifying the original array
void sortAscendInPlace();	Sort in place; ascending
void sortDescendInPlace();	Sort in place; descending

template<class T>
class TigrArray2D
Two-dimensional array of objects of type T.  Fixed dimensions.  Define DEBUG to turn on bounds-checking.  Use standard A[i][j] notation to access elements (by reference).  First dimension is rows, second dimension is columns.
TigrArray2D(int rows,int cols);	constructor
TigrArray2D(const TigrArray2D &);	copy constructor
virtual ~TigrArray2D();	destructor
RowIn2DArray<T> operator[](int);	Using a single index (i.e. array[i]) returns a RowIn2DArray object, which can then accept a second index.  Thus, array[i][j] gives you a reference to an object of type T.
const RowIn2DArray<T> operator[](int) const;	Const version of []
T &index(int,int);	Same as array[i][j]
int getFirstDim() const;	Returns first dimension size
int getSecondDim() const;	Returns second dimension size
void printOn(ostream &) const;	Print on ostream (used by operator <<)
void readFrom(istream &);	Reads an array from an istream, filling up rows before columns (first index increases faster than second)
void setAllTo(T);	Store given object at all locations
void resize(int rows,int cols);	Delete array and resize to given dimensions
void saveBytes(TigrFile &);	Write raw bytes into file
void loadBytes(TigrFile &);	Read raw bytes from fil

template<class T>
class TigrBinaryTree
Binary tree in which each node has a pointer to its children but not to its parent.  If you want faster performance, use TigrFastBinTree, which stores a parent pointer in each node.  T is the stored data type (not the node type -- a node type is defined within the binary tree that has a T member).
TigrBinaryTree(TigrComparator<T>& = *new DirectComparator<T>());	constructor - requires a comparator over T's to defined the ordering
virtual ~TigrBinaryTree();	destructor
virtual bool insert(T);	Insert an element
virtual T &maximum() const;	Get the largest element
virtual T &minimum() const;	Get the smallest element
virtual unsigned getCardinality();	Find out how many elements are in the tree
bool isEmpty() const;	True iff tree is currently empty
virtual void purge();	Remove all objects from the tree
TigrBinTreeIter<T> begin();	Get begin iterator
TigrBinTreeIter<T> end();	Get ending iterator
void remove(T);	Remove object from tree
bool getPredecessor(T X,T &Y);	Find predecessor of X and store that in Y; returns false iff none found
bool getSuccessor(T X,T &Y);	Find successor of X and store that in Y; returns false iff none found
TigrComparator<T> &getComparator();	Returns comparator supplied in constructor

template<class T>
class TigrBinTreeIter
Iterator for binary trees (TigrBinaryTree).  Three iteration types: PREORDER, POSTORDER, INORDER.
TigrBinTreeIter(TigrBinaryTree<T> *,IterationType=INORDER);	constructor; defaults to INORDER
T &operator*();	Returns current element
operator bool();	True iff iteration is not finished
TigrBinTreeIter<T> &operator++();	Advance iterator to next element
bool operator==(const TigrBinTreeIter<T> &) const;	True iff this iterator points to same element as the other iterator

class TigrBitSet
A set represented by a bit-vector, with one bit per element.
TigrBitSet(unsigned long Size=0);	constructor - build set with given max size
virtual ~TigrBitSet();	virtual destructor
void operator =(TigrBitSet &);	copy assignment operator
void operator -=(TigrBitSet &);	Subtract other set from this one and store the result here
void operator +=(TigrBitSet &);	Store union of this set and that set here
void operator *=(TigrBitSet &);	Store intersection of that set and this set here
bool operator ==(TigrBitSet &);	True iff this set has same elements as that one
TigrBitSet *operator -(TigrBitSet &);	Subtract other set from this one and return resulting set
TigrBitSet *operator +(TigrBitSet &);	Compute union of this set and that set and return the result
TigrBitSet *operator *(TigrBitSet &);	Compute intersection of this set and that set and return the result
bool isMember(unsigned long index);	True iff given bit is set (element is present)
unsigned long cardinality();	Return number of elements in set
unsigned long getMaxSize();	Return max capacity of this set
void addAll();	Become the universal set (all bits on)
void addMember(unsigned long index);	Insert element into set
void complement();	Complement all bits
void getRawBytes(unsigned char *&,unsigned long &maxSize, unsigned long &numBytes);	Returns underlying representation
void load(FILE *fp);	Loads set from file that was previous saved  via save(FILE*)
void purge();	Become the empty set
void removeMember(unsigned long index);	Remove element from set
void replaceRawBytes(unsigned char *,unsigned long maxSize, unsigned long numBytes);	Replace underlying bytes - useful if you just want to use this class to manipulate long bit vectors
void save(FILE *fp);	Store raw bytes in file
void setSize(unsigned long Size);	Delete set and reallocate to new size

class TigrChi2FitTest
Computes a chi-squared goodness-of-fit test.
TigrChi2FitTest(TigrVector<int> &observedCounts, TigrVector<int> &expectedCounts, TigrChi2Table &);	constructor - takes observed counts and expected counts for paired data, and a chi-squared distribution object, and performs the goodness-of-fit test
bool goodFit();	Ttrue if good fit
double getChiSquared();	Returns chi-squared statistic
double getP();	Returns P-value associated with chi-squared statistic

class TigrChi2IndepTest
Computes a chi-squared test of independence.
TigrChi2IndepTest(TigrArray2D<int> &contingencyTable,TigrChi2Table &);	constructor - takes a contingency table of observed counts and a chi-squared distribution, and performs the test
bool areIndependent();	True iff variables are probably independent
double getChiSquared();	Returns chi-squared statistic
double getP();	Returns P-value associated with chi-squared statistic
inline bool areDependent();	True iff variables are probably not independent

class TigrChi2Table
Stores chi-squared distribution table.  DEFAULT_PATH="tigr++/chi-squared.txt".  Employs linear interpolation.
TigrChi2Table(TigrString filename=DEFAULT_PATH);	constructor - takes path to file containing chi-squared distribution table
float lookupChi(int df,float alpha);	Get chi-squared value for given degrees of freedom df and alpha level
float lookupP(int df,float chiSquared);	Get alpha level for given chi-squared value and degrees of freedom

class TigrCommandLine
Parses command line and provides access to arguments and options.
TigrCommandLine(int argc,char *argv[],const char *options);	constructor - options are of the form "a:bc:" where a and c take parameters and b does not
TigrString arg(int);	Return ith argument; first argument has index 0
TigrString optParm(char);	Return the parameter supplied with the given option
bool option(char);	True iff the user specified "-c" for char c
int numArgs();	Number of args on command line (not including options)

template <class T>
class TigrComparator
Abstract base class for comparators.  Used in sorting and in sorted data structures.  Subclass this class and override the operators for your data type.
virtual bool equal(T &a,T &b)=0;	a==b?
virtual bool greater(T &a,T &b)=0;	a>b?
virtual bool less(T &a,T &b)=0;	a<b?

template <class T>
class DirectComparator : public TigrComparator<T>
A comparator for type T that compares T objects using the native <, >, and == operators.
virtual bool equal(T &a,T &b);	a==b?
virtual bool greater(T &a,T &b);	a>b?
virtual bool less(T &a,T &b);	a<b?

class TigrComplexNum
Complex number having a real part and an imaginary part
TigrComplexNum(double real=0.0,double imag=0.0);	constructor
TigrComplexNum operator+(const TigrComplexNum &);	complex addition
TigrComplexNum operator*(const TigrComplexNum &);	complex multiplication
TigrComplexNum getConjugate();	returns (r,-i)
double &getImag();	access to imaginary part
double &getReal();	access to real part
double getImag() const;	returns imaginary part
double getModulus() const;	sqrt(r*r + i*i)
double getReal() const;	returns real part

class TigrConfigFile
Parses a configuration file consisting of lines of the form X=Y. # starts a comment line.  X and Y may be surrounded by spaces but may not contain spaces within them.  X is the "attribute" and Y is the "value".  This class stores (attribute,value) pairs and supports queries on attribute values.
TigrConfigFile(TigrString fname);	constructor - loads configuration file
virtual TigrString lookup(TigrString attr);	returns the value associated with the given attribute, or the empty string if not defined in the config file
virtual TigrString lookupOrDie(TigrString attr);	returns value of given attribute, or throws exception if not found in config file
virtual double getDoubleOrDie(TigrString attr);	looks up attribute and converts value to double, or throws exception if undefined
virtual float getFloatOrDie(TigrString attr);	looks up attribute and converts value to float, or throws exception if undefined
virtual int getIntOrDie(TigrString attr);	looks up attribute and converts value to int, or throws exception if undefined
virtual long getLongOrDie(TigrString attr);	looks up attribute and converts to long, or throws exception if undefined

class TigrContingencyTbl : public TigrIntArray2D
A contingency table of counts for use with TigrChi2IndepTest (chi-squared test of independence) or TigrMutInfo (mutual information)
TigrContingencyTbl(int width,int height);	constructor
int getColumnTotal(int column);	Returns sum of a column (call computeTotals() first!)
int getGrandTotal();	Returns grand total (call computeTotals() first!)
int getRowTotal(int row);	Returns sum of a row (call computeTotals() first!)
void computeTotals();	Computes all totals

class TigrDblMatrix;
A matrix of doubles.  Provides many matrix operations for linear algebra.  Used by the regression package.
TigrDblMatrix(int rows,int columns);	constructor
TigrDblMatrix(const TigrDblMatrix &other);	copy constructor
virtual double operator()(int row,int col) const;	access const element
virtual double &operator()(int row,int col);	access element
TigrDblMatrix &operator=(TigrDblMatrix &);	copy assignment operator
bool invert(TigrDblMatrix &resultingMatrix) const;	compute inverse of this matrix and store it in the given matrix -- returns false if noninvertible
virtual int getNumColumns() const;	returns number of columns in matrix
virtual int getNumRows() const;	returns number of rows in matrx
void addRowMultiple(int sourceRow,int destinationRow,double factor);	add a multiple of one row to another row (used by TigrGaussJordan)
void getColumn(int column,TigrDblArray1D &into) const;	copy a column into an array
void getRow(int row,TigrDblArray1D &into) const;	copy a row into an array
void multiplyRowBy(int whichRow,double factor);	multiply a row by some factor and store the resulting row back in its place
void printOn(ostream &);	used by operator <<
void setAllTo(double d);
